pinia源码学习3——defineStore

前言#

昨天我们看了cretePinia的逻辑，了解了初始化的逻辑。

今天我们来看下defineStore。

defineStore#

切换测试用例#

昨天我们用的测试用例是没有数据的，今天我们换一个：

这是官方提供的：

const useA = defineStore('a', {
    state: () => ({ a: 'a' }),
})

it('retrieves the root state of one store', () => {
    const pinia = createPinia()
    useA(pinia)
    expect(pinia.state.value).toEqual({
      a: { a: 'a' },
    })
  })

不过我一般的写法是setup stores：

export const useCounterStore = defineStore('counter', () => {
  const count = ref(0)

  function $reset() {
    count.value = 0
  }

  return { count, $reset }
})

所以我这里修改下测试用例

const useC = defineStore('c', () => {
	const user = reactive({
      name: 'c',
      gender: 'male',
      age: 18,
     })
    return {
      user,
    }
  })

it('retrieves the root state of one store', () => {
    const pinia = createPinia()
    useC(pinia)
    expect(pinia.state.value).toEqual({
      c: {
        user: {
          name: 'c',
          gender: 'male',
          age: 18,
        },
      },
    })
  })

源码#

前面一大段的函数重载

export function defineStore<
  Id extends string,
  S extends StateTree = {},
  G extends _GettersTree<S> = {},
  // cannot extends ActionsTree because we loose the typings
  A /* extends ActionsTree */ = {},
>(
  id: Id,
  options: Omit<DefineStoreOptions<Id, S, G, A>, 'id'>
): StoreDefinition<Id, S, G, A>

/**
 * Creates a `useStore` function that retrieves the store instance
 *
 * @param options - options to define the store
 */
export function defineStore<
  Id extends string,
  S extends StateTree = {},
  G extends _GettersTree<S> = {},
  // cannot extends ActionsTree because we loose the typings
  A /* extends ActionsTree */ = {},
>(options: DefineStoreOptions<Id, S, G, A>): StoreDefinition<Id, S, G, A>

/**
 * Creates a `useStore` function that retrieves the store instance
 *
 * @param id - id of the store (must be unique)
 * @param storeSetup - function that defines the store
 * @param options - extra options
 */
export function defineStore<Id extends string, SS>(
  id: Id,
  storeSetup: () => SS,
  options?: DefineSetupStoreOptions<
    Id,
    _ExtractStateFromSetupStore<SS>,
    _ExtractGettersFromSetupStore<SS>,
    _ExtractActionsFromSetupStore<SS>
  >
): StoreDefinition<
  Id,
  _ExtractStateFromSetupStore<SS>,
  _ExtractGettersFromSetupStore<SS>,
  _ExtractActionsFromSetupStore<SS>
>

我们来看下核心代码：

export function defineStore(
  // TODO: add proper types from above
  idOrOptions: any,
  setup?: any,
  setupOptions?: any
): StoreDefinition {
  let id: string
  let options:
    | DefineStoreOptions<
        string,
        StateTree,
        _GettersTree<StateTree>,
        _ActionsTree
      >
    | DefineSetupStoreOptions<
        string,
        StateTree,
        _GettersTree<StateTree>,
        _ActionsTree
      >

  const isSetupStore = typeof setup === 'function'
  if (typeof idOrOptions === 'string') {
    id = idOrOptions
    // the option store setup will contain the actual options in this case
    options = isSetupStore ? setupOptions : setup
  } else {
    options = idOrOptions
    id = idOrOptions.id

    if (__DEV__ && typeof id !== 'string') {
      throw new Error(
        `[🍍]: "defineStore()" must be passed a store id as its first argument.`
      )
    }
  }

  function useStore(pinia?: Pinia | null, hot?: StoreGeneric): StoreGeneric {
    const hasContext = hasInjectionContext()
    pinia =
      // in test mode, ignore the argument provided as we can always retrieve a
      // pinia instance with getActivePinia()
      (__TEST__ && activePinia && activePinia._testing ? null : pinia) ||
      (hasContext ? inject(piniaSymbol, null) : null)
    if (pinia) setActivePinia(pinia)

    if (__DEV__ && !activePinia) {
      throw new Error(
        `[🍍]: "getActivePinia()" was called but there was no active Pinia. Are you trying to use a store before calling "app.use(pinia)"?\n` +
          `See https://pinia.vuejs.org/core-concepts/outside-component-usage.html for help.\n` +
          `This will fail in production.`
      )
    }

    pinia = activePinia!

    if (!pinia._s.has(id)) {
      // creating the store registers it in `pinia._s`
      if (isSetupStore) {
        createSetupStore(id, setup, options, pinia)
      } else {
        createOptionsStore(id, options as any, pinia)
      }

      /* istanbul ignore else */
      if (__DEV__) {
        // @ts-expect-error: not the right inferred type
        useStore._pinia = pinia
      }
    }

    const store: StoreGeneric = pinia._s.get(id)!

    if (__DEV__ && hot) {
      const hotId = '__hot:' + id
      const newStore = isSetupStore
        ? createSetupStore(hotId, setup, options, pinia, true)
        : createOptionsStore(hotId, assign({}, options) as any, pinia, true)

      hot._hotUpdate(newStore)

      // cleanup the state properties and the store from the cache
      delete pinia.state.value[hotId]
      pinia._s.delete(hotId)
    }

    if (__DEV__ && IS_CLIENT) {
      const currentInstance = getCurrentInstance()
      // save stores in instances to access them devtools
      if (
        currentInstance &&
        currentInstance.proxy &&
        // avoid adding stores that are just built for hot module replacement
        !hot
      ) {
        const vm = currentInstance.proxy
        const cache = '_pStores' in vm ? vm._pStores! : (vm._pStores = {})
        cache[id] = store
      }
    }

    // StoreGeneric cannot be casted towards Store
    return store as any
  }

  useStore.$id = id

  return useStore
}

代码量不多，就不做删减了。

idOrOptions：我们defineStore的第一个参数，作为唯一标识符。

setup：我们传入的第二个参数，我们这里传入了一个函数：

() => {
    const user = __vite_ssr_import_3__.reactive({
    	name: "c",
    	gender: "male",
        age: 18
    });
    return {
        user
    };
}

isSetupStore：不多说，我们的写法自然就是setup store，注意，只要传入函数就会被认定是setup store的写法。

最后它返回一个useStore的函数，并把我们的唯一标识符赋值给这个函数$id。

而这个useStore的函数就是我们业务代码中引入的hook，我们需要执行这个hook才能拿到最终的数据：

const userStore = useC()

这里我们不需要传入pinia作为参数，因为我们有全局activePinia。

然后我们来看下useStore执行的逻辑。

hasInjectionContext：这个函数来自于vue（vue-demi）：
typescript · readonly
```
function hasInjectionContext() {
  return !!(currentInstance || currentRenderingInstance || currentApp);
}
```
查看是否可以执行inject逻辑，前面一章我们说过了currentInstance、currentRenderingInstsance的作用以及provide/inject的实现逻辑，所以这里不多说。
pinia = inject(piniaSymbol, null)：没啥好说的，从当前组件实例中拿到pinia，前面一章我们知道了install的时候这货会用vue的provide将自己注入所有组件实例中，所以理论上是拿得到的。
if (pinia) setActivePinia(pinia)：这里是将全局的activePinia设置成当前组件实例绑定的pinia实例。你可呢在疑惑为什么要这么做，install到vue根组件的时候不是已经这么做了吗？为什么还要再设置一次？因为不一定只有一个vue根组件，也不一定只有一个pinia实例。可能存在两个pinia实例，比如：
typescript · readonly
```
  it('does not mix up different applications', () => {
    const pinia1 = createPinia()
    const pinia2 = createPinia()
    useA(pinia1)
    useB(pinia2)
    expect(pinia1.state.value).toEqual({
      a: { a: 'a' },
    })
    expect(pinia2.state.value).toEqual({
      b: { b: 'b' },
    })
  })

const app1 = createApp(App1).mount('a').use(pinia1);
const app2 = createApp(App2).mount('b').use(pinia2);
```
这就是俩pinia实例，另外这个项目中可能存在多个vue根组件实例，每个实例单独use一个pinia实例。但是我们只有一个activePinia位置！这玩意儿全局只有一个！。那么这个时候activePinia指向就不一定准了。
pinia._s：_s: Map<string, StoreGeneric>，存放的是defineStore里的数据，key自然就是defineStore第一个参数。
createSetupStore：这玩意儿代码有些长。。我们等会开个小章节说下，这里先跳过
createOptionsStore：这个和createSetupStore放到一起说，所以这里也先跳过
const store: StoreGeneric = pinia._s.get(id)!：这货就是我们useXX返回的数据，指向我们定义的store数据

剩余部分的代码是和开发阶段热更新有关的，官方链接：HMR (Hot Module Replacement) | Pinia (vuejs.org)

这里简单说下：如果是vite，那么开箱即用，vite支持自定义热更新内容（当然，webpack等也支持，不过写法不一样）：HMR API | Vite (vitejs.dev)

// auth.js
import { defineStore, acceptHMRUpdate } from 'pinia'

export const useAuth = defineStore('auth', {
  // options...
})

// make sure to pass the right store definition, `useAuth` in this case.
if (import.meta.hot) {
  import.meta.hot.accept(acceptHMRUpdate(useAuth, import.meta.hot))
}

这么做就可以搭vite热更新的车了。

具体如何实现的，因为涉及到vite热更新的原理，我们以后再分析，现阶段先跳过。

createSetupStore#

这货代码较长，我这里就不贴整体的了，我们拆开了一部分一部分分析：

函数整体：

function createSetupStore<
  Id extends string,
  SS extends Record<any, unknown>,
  S extends StateTree,
  G extends Record<string, _Method>,
  A extends _ActionsTree,
>(
  $id: Id,
  setup: () => SS,
  options:
    | DefineSetupStoreOptions<Id, S, G, A>
    | DefineStoreOptions<Id, S, G, A> = {},
  pinia: Pinia,
  hot?: boolean,
  isOptionsStore?: boolean
): Store<Id, S, G, A> {
    // ...
      const store: Store<Id, S, G, A> = reactive(
    	__DEV__ || (__USE_DEVTOOLS__ && IS_CLIENT)
      ? assign(
          {
            _hmrPayload,
            _customProperties: markRaw(new Set<string>()), // devtools custom properties
          },
          partialStore
          // must be added later
          // setupStore
        )
      : partialStore
  	) as unknown as Store<Id, S, G, A>

    pinia._s.set($id, store as Store)
    // ...
    return store
}

可以看到最终是返回一个reactive包裹的响应式store数据，这个数据就是最终我们useXX返回的数据,对应前面useStore函数的返回store。

然后我们来看下这个partialStore：

  const partialStore = {
    _p: pinia,
    // _s: scope,
    $id,
    $onAction: addSubscription.bind(null, actionSubscriptions),
    $patch,
    $reset,
    $subscribe(callback, options = {}) {
      const removeSubscription = addSubscription(
        subscriptions,
        callback,
        options.detached,
        () => stopWatcher()
      )
      const stopWatcher = scope.run(() =>
        watch(
          () => pinia.state.value[$id] as UnwrapRef<S>,
          (state) => {
            if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(
                {
                  storeId: $id,
                  type: MutationType.direct,
                  events: debuggerEvents as DebuggerEvent,
                },
                state
              )
            }
          },
          assign({}, $subscribeOptions, options)
        )
      )!

      return removeSubscription
    },
    $dispose,
  } as _StoreWithState<Id, S, G, A>

_p：这里注意和pinia实例的_p区分开来，pinia实例的_p指向pinia的插件。这里则指向pinia实例。

然后没啥好说的了，这就是在初始化一个store实例。

我们接着看下每个property是干啥用的。

$onAction

首先是犯下傲慢的$onAction：Interface: _StoreWithState | Pinia (vuejs.org)

$onAction: addSubscription.bind(null, actionSubscriptions)

export function addSubscription<T extends _Method>(
  subscriptions: T[],
  callback: T,
  detached?: boolean,
  onCleanup: () => void = noop
) {
  subscriptions.push(callback)

  const removeSubscription = () => {
    const idx = subscriptions.indexOf(callback)
    if (idx > -1) {
      subscriptions.splice(idx, 1)
      onCleanup()
    }
  }

  if (!detached && getCurrentScope()) {
    onScopeDispose(removeSubscription)
  }

  return removeSubscription
}

就是一个简单的订阅和取消订阅的方法，这里只是订阅，还没涉及到发布。

所以这个$onAction就是用来订阅的，另外根据官方文档的描述：

Setups a callback to be called every time an action is about to get invoked

这货可以用在每次action触发后的回调。

返回一个函数用来手动注销回调。

看下基础用法：

store.$onAction(({ after, onError }) => {
 // Here you could share variables between all of the hooks as well as
 // setting up watchers and clean them up
 after((resolvedValue) => {
   // can be used to cleanup side effects
.  // `resolvedValue` is the value returned by the action, if it's a
.  // Promise, it will be the resolved value instead of the Promise
 })
 onError((error) => {
   // can be used to pass up errors
 })
})

然后我们再来看下$patch

$patch

Interface: _StoreWithState | Pinia (vuejs.org)

在看代码之前，我们先看下基础用法：

          store.$patch({ user })
		 // or
          store.$patch((state) => {
            state.user = name
          })

然后看下代码

  // avoid triggering too many listeners
  // https://github.com/vuejs/pinia/issues/1129
  let activeListener: Symbol | undefined
  function $patch(stateMutation: (state: UnwrapRef<S>) => void): void
  function $patch(partialState: _DeepPartial<UnwrapRef<S>>): void
  function $patch(
    partialStateOrMutator:
      | _DeepPartial<UnwrapRef<S>>
      | ((state: UnwrapRef<S>) => void)
  ): void {
    let subscriptionMutation: SubscriptionCallbackMutation<S>
    isListening = isSyncListening = false
    // reset the debugger events since patches are sync
    /* istanbul ignore else */
    if (__DEV__) {
      debuggerEvents = []
    }
    if (typeof partialStateOrMutator === 'function') {
      partialStateOrMutator(pinia.state.value[$id] as UnwrapRef<S>)
      subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    } else {
      mergeReactiveObjects(pinia.state.value[$id], partialStateOrMutator)
      subscriptionMutation = {
        type: MutationType.patchObject,
        payload: partialStateOrMutator,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    }
    const myListenerId = (activeListener = Symbol())
    nextTick().then(() => {
      if (activeListener === myListenerId) {
        isListening = true
      }
    })
    isSyncListening = true
    // because we paused the watcher, we need to manually call the subscriptions
    triggerSubscriptions(
      subscriptions,
      subscriptionMutation,
      pinia.state.value[$id] as UnwrapRef<S>
    )
  }

代码稍微复杂了点。

首先，如果传入的是函数，那么会将store实例的state传递给我们传入和函数，否则直接合并俩state。。前面一直没有解释类型，因为可读性较差，另外是觉得没必要，现在是时候看下UnwrapRef<T>了：

export type UnwrapRef<T> = T extends ShallowRef<infer V> ? V : T extends Ref<infer V> ? UnwrapRefSimple<V> : UnwrapRefSimple<T>;

export type ShallowRef<T = any> = Ref<T> & {
    [ShallowRefMarker]?: true;
};

export interface Ref<T = any> {
    value: T;
    /**
     * Type differentiator only.
     * We need this to be in public d.ts but don't want it to show up in IDE
     * autocomplete, so we use a private Symbol instead.
     */
    [RefSymbol]: true;
}

type UnwrapRefSimple<T> = T extends Builtin | Ref | RefUnwrapBailTypes[keyof RefUnwrapBailTypes] | {
    [RawSymbol]?: true;
} ? T : T extends Map<infer K, infer V> ? Map<K, UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof Map<any, any>>> : T extends WeakMap<infer K, infer V> ? WeakMap<K, UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof WeakMap<any, any>>> : T extends Set<infer V> ? Set<UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof Set<any>>> : T extends WeakSet<infer V> ? WeakSet<UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof WeakSet<any>>> : T extends ReadonlyArray<any> ? {
    [K in keyof T]: UnwrapRefSimple<T[K]>;
} : T extends object & {
    [ShallowReactiveMarker]?: never;
} ? {
    [P in keyof T]: P extends symbol ? T[P] : UnwrapRef<T[P]>;
} : T;


S extends StateTree,

不是我不想解释，实在是太类型体操了。

简单的说下UnwrapRef<T>的作用，就是用来取消ref包裹数据的那一层。

原本我们需要调用.value才能访问到这个数据，使用UnwrapRef<T>之后就不需要了。

来看下官方的例子：Reactivity Fundamentals | Vue.js (vuejs.org)

const count = ref(0)
const state = reactive({
  count
})

console.log(state.count) // 0

state.count = 1
console.log(count.value) // 1

当它被赋值给一个reactive的属性的时候它会自动解除外面那一层。

前面我们知道了usexx返回的就是一个reactive的store实例，所以这里state自然就是UnwrapRef。

不过这里你可能会有疑惑，为什么传给我们回调的是pinia.state.value[$id]

这就需要我们回到createPinia那里：

  const scope = effectScope(true)
  // NOTE: here we could check the window object for a state and directly set it
  // if there is anything like it with Vue 3 SSR
  const state = scope.run<Ref<Record<string, StateTree>>>(() =>
    ref<Record<string, StateTree>>({})
  )!

这里的state就是上面的pinia.state，因为pinia本身是raw的，所以state并不能变成UnwrapRef。

ok，但是这里还有个问题，初始化的时候是空的，这里却是从里面拿出store来，这不对啊。

实际上前面还有逻辑我没给出：

  const initialState = pinia.state.value[$id] as UnwrapRef<S> | undefined

  // avoid setting the state for option stores if it is set
  // by the setup
  if (!isOptionsStore && !initialState && (!__DEV__ || !hot)) {
    /* istanbul ignore if */
    if (isVue2) {
      set(pinia.state.value, $id, {})
    } else {
      pinia.state.value[$id] = {}
    }
  }

	// ...
    if (typeof partialStateOrMutator === 'function') {
      partialStateOrMutator(pinia.state.value[$id] as UnwrapRef<S>)
      subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    }
	// ...

就是在这里，因为我们传给$patch的是函数，所以我们是自己忘state上面加数据的，所以这里只需要判断是否为空，为空初始化这个实例在state上的数据即可。

那么到这我们就知道了为什么这里是从pinia.state.value[$id]中拿到的数据。

貌似扯的有些远了，我们回到之前的代码，在执行完我们传入的函数之后。

我们前面看的$onAction就是设置回调可以在每次action之后执行回调，那么这里我们在更新数据之后就需要触发回调（pinia只有action）。

则例isListening和isSyncListening俩参数暂时还不清楚是干什么用的，所以先暂时搁置，后面遇到再解释。

triggerSubscriptions：

export function triggerSubscriptions<T extends _Method>(
  subscriptions: T[],
  ...args: Parameters<T>
) {
  subscriptions.slice().forEach((callback) => {
    callback(...args)
  })
}

就是简单的执行回调，注意是slice是clone一个，而不是直接占用。

这里args里有俩参数：

if (__DEV__) {
   debuggerEvents = []
}
// args第一个参数
subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
 }
// args第二个参数
pinia.state.value[$id] as UnwrapRef<S>

注意这里第一个参数里有一个debuggerEvents，只有开发阶段才能使用，我们可以往里面传入debug回调。

到这我们暂时只知道如何存储，还不知道如何调用，等会遇到了我们再说。

ok, $patch分析到这，我们有俩个点还没分析：

debuggerEvents
isListening以及isSyncListening

然后我们来看下$reset

$reset

Interface: _StoreWithState | Pinia (vuejs.org)

Resets the store to its initial state by building a new state object.

不多说，直接看代码

  const $reset = isOptionsStore
    ? function $reset(this: _StoreWithState<Id, S, G, A>) {
        const { state } = options as DefineStoreOptions<Id, S, G, A>
        const newState = state ? state() : {}
        // we use a patch to group all changes into one single subscription
        this.$patch(($state) => {
          assign($state, newState)
        })
      }
    : /* istanbul ignore next */
      __DEV__
      ? () => {
          throw new Error(
            `🍍: Store "${$id}" is built using the setup syntax and does not implement $reset().`
          )
        }
      : noop

可以看到只有使用optionStore的时候才可行，为什么呢？

因为我们用的是setup语法，没有state函数。

总之，setupStore需要开发者手动实现初始化函数，因为不像optionStore一样是一个对象很好管理。

然后我们来看下$subscribe

$subscribe

Interface: _StoreWithState | Pinia (vuejs.org)

Setups a callback to be called whenever the state changes. It also returns a function to remove the callback. Note that when calling store.$subscribe() inside of a component, it will be automatically cleaned up when the component gets unmounted unless detached is set to true.

{
// ...
$subscribe(callback, options = {}) {
      const removeSubscription = addSubscription(
        subscriptions,
        callback,
        options.detached,
        () => stopWatcher()
      )
      const stopWatcher = scope.run(() =>
        watch(
          () => pinia.state.value[$id] as UnwrapRef<S>,
          (state) => {
            if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(
                {
                  storeId: $id,
                  type: MutationType.direct,
                  events: debuggerEvents as DebuggerEvent,
                },
                state
              )
            }
          },
          assign({}, $subscribeOptions, options)
        )
      )!

      return removeSubscription
    }
// ...
}

先将我们的回调放入到订阅器中，不过和前面$onAction不同的是这里还传入了一个() => stopWatcher()作为addSubscription的第四个参数onCleanup，在执行函数返回的函数即注销回调会执行这个onCleanup。触发stopWatcher
stopWatcher中有个scope，我们来看下这货是从哪来的：

// pinia里的
function createSetupStore (...) {
    let scope!: EffectScope
    // ...
 const partialStore = { ... };
 const store = reactive(...);

 const runWithContext = (pinia._a && pinia._a.runWithContext) || fallbackRunWithContext

  // TODO: idea create skipSerialize that marks properties as non serializable and they are skipped
  const setupStore = runWithContext(() =>
    pinia._e.run(() => (scope = effectScope()).run(setup)!)
  )!
}


// vue里的
    /**
     * Runs a function with the app as active instance. This allows using of `inject()` within the function to get access
     * to variables provided via `app.provide()`.
     *
     * @param fn - function to run with the app as active instance
     */
    runWithContext<T>(fn: () => T): T;

const app = {
    // ...
      runWithContext(fn) {
        const lastApp = currentApp;
        currentApp = app;
        try {
          return fn();
        } finally {
          currentApp = lastApp;
        }
      }
    // ...
}

_a：这货前面说过了，就是这个pinia实例注册的那个vue根实例
runWithContext：这个则是vue里的函数，用来确保当前执行函数的上下文是对应的vue根实例。
_e： EffectScope，这货是pinia实例初始化即createPinia时触发的effectscope。

简单的说就是创建一个当前store的effectScope，用来收集store（我们传入的setup函数）里的响应式数据

然后回到stopWatcher中，scope收集一个watch，watch的作用是只要当前store实例响应式数据发生变化就执行回调。注意是当前store实例，而$onAction则是任一store实例执行action（即$patch）之后。

这里我们遇到了前面没说的isSyncListening和isListening字段

然后我们结合$patch里的逻辑，整理下：

let isListening: boolean // set to true at the end
let isSyncListening: boolean // set to true at the end
let activeListener: Symbol | undefined
const partialStore = {
    // ...
	$patch () {

   		isListening = isSyncListening = false
    	// ...
		const myListenerId = (activeListener = Symbol())
    	nextTick().then(() => {
      		if (activeListener === myListenerId) {
        		isListening = true
      		}
    	})
    	isSyncListening = true
    // ...
	}
    // ...
    $subscribe () {
        // ...
        const stopWatcher = scope.run(() => watch(
        	// ...
             if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(...)
			}
        ))
        // ...
    }
}

export interface WatchOptionsBase extends DebuggerOptions {
    flush?: 'pre' | 'post' | 'sync';
}

这里需要补充watch的知识：Watchers | Vue.js (vuejs.org)

简单的说，就是用来解决大数据量操作时同步触发大量watch回调的问题，所以vue针对这点增加了watch的这一特性，可以让开发者定义什么时候执行watch回调。

默认情况下，watch回调是在父组件更新后子组件DOM更新前触发（flush: sync），这么做是避免watch里改动数据引起重复渲染。

当然，如果你有这方面的想法，想在子组件（当前组件）更新之后再执行，可以设置flush: post：

watch(source, callback, {
  flush: 'post'
})

watchEffect(callback, {
  flush: 'post'
})

import { watchPostEffect } from 'vue'

watchPostEffect(() => {
  /* executed after Vue updates */
})

或者说在这之前获取：

watch(source, callback, {
  flush: 'sync'
})

watchEffect(callback, {
  flush: 'sync'
})

import { watchSyncEffect } from 'vue'

watchSyncEffect(() => {
  /* executed synchronously upon reactive data change */
})

ok，回到我们的代码中。在知道了watch可以手动调整执行回调timing之后，我们知道了这里nextTick + activeListener === myListenerId的作用，就是用来判断当前是否是flush: post执行，如果是，那么isListening = true。

而$subscribe里的watch只能在flush和post两种情况下执行，记录isListening是确保不会执行错回调，毕竟这个回调只能在这个store实例数据刷新后执行。

ok，还剩最后一个$dispose

$dispose

Interface: _StoreWithState | Pinia (vuejs.org)

  function $dispose() {
    scope.stop()
    subscriptions = []
    actionSubscriptions = []
    pinia._s.delete($id)
  }

这货不用多说，就是remove这个store实例。

ok，跳出partialStrore回到我们的createSetupStore函数中

在执行了runWithContext之后我们拿到了setupStore，为了方便分析，我加了点其它的东西

然后我们接着看代码（部分dev和hmr相关的代码省略）：

// ...
for (const key in setupStore) {
    const prop = setupStore[key]

    if ((isRef(prop) && !isComputed(prop)) || isReactive(prop)) {
        if (!isOptionsStore) {
        	// in setup stores we must hydrate the state and sync pinia state tree with the refs the 			user just created
        	if (initialState && shouldHydrate(prop)) {
          	if (isRef(prop)) {
            	prop.value = initialState[key]
          	} else {
            	// probably a reactive object, lets recursively assign
            	// @ts-expect-error: prop is unknown
            	mergeReactiveObjects(prop, initialState[key])
          	}
        }
        // transfer the ref to the pinia state to keep everything in sync
        /* istanbul ignore if */
        if (isVue2) {
          set(pinia.state.value[$id], key, prop)
        } else {
          pinia.state.value[$id][key] = prop
        }
      }
    } else if (typeof prop === 'function') {
             // @ts-expect-error: we are overriding the function we avoid wrapping if
      		const actionValue = __DEV__ && hot ? prop : wrapAction(key, prop)
      		// this a hot module replacement store because the hotUpdate method needs
      		// to do it with the right context
      		/* istanbul ignore if */
      		if (isVue2) {
        		set(setupStore, key, actionValue)
      		} else {
        		// @ts-expect-error
        		setupStore[key] = actionValue
      		}
             // list actions so they can be used in plugins
      		// @ts-expect-error
      		optionsForPlugin.actions[key] = prop
    }
 // ...
 }
// ...

/**
 * Returns whether a value should be hydrated
 *
 * @param obj - target variable
 * @returns true if `obj` should be hydrated
*/
export function isPlainObject(
  // eslint-disable-next-line @typescript-eslint/no-explicit-any
  o: any
): o is StateTree {
  return (
    o &&
    typeof o === 'object' &&
    Object.prototype.toString.call(o) === '[object Object]' &&
    typeof o.toJSON !== 'function'
  )
}
const skipHydrateSymbol = Symbol();
function shouldHydrate(obj: any) {
  return isVue2
    ? /* istanbul ignore next */ !skipHydrateMap.has(obj)
    : !isPlainObject(obj) || !obj.hasOwnProperty(skipHydrateSymbol)
}

shouldHydrate：是否需要注入，如果是对象并且不在store中，那就需要合并
mergeReactiveObjects：篇幅问题，这里就不贴代码了，就是在合并响应式数据

wrapAction：这货得看下代码：

  /**
   * Wraps an action to handle subscriptions.
   *
   * @param name - name of the action
   * @param action - action to wrap
   * @returns a wrapped action to handle subscriptions
   */
  function wrapAction(name: string, action: _Method) {
    return function (this: any) {
      setActivePinia(pinia)
      const args = Array.from(arguments)

      const afterCallbackList: Array<(resolvedReturn: any) => any> = []
      const onErrorCallbackList: Array<(error: unknown) => unknown> = []
      function after(callback: _ArrayType<typeof afterCallbackList>) {
        afterCallbackList.push(callback)
      }
      function onError(callback: _ArrayType<typeof onErrorCallbackList>) {
        onErrorCallbackList.push(callback)
      }

      // @ts-expect-error
      triggerSubscriptions(actionSubscriptions, {
        args,
        name,
        store,
        after,
        onError,
      })

      let ret: unknown
      try {
        ret = action.apply(this && this.$id === $id ? this : store, args)
        // handle sync errors
      } catch (error) {
        triggerSubscriptions(onErrorCallbackList, error)
        throw error
      }

      if (ret instanceof Promise) {
        return ret
          .then((value) => {
            triggerSubscriptions(afterCallbackList, value)
            return value
          })
          .catch((error) => {
            triggerSubscriptions(onErrorCallbackList, error)
            return Promise.reject(error)
          })
      }

      // trigger after callbacks
      triggerSubscriptions(afterCallbackList, ret)
      return ret
    }
  }

它是用于普通函数的。简单的说就是包裹一层普通函数，让它也能触发action回调以及函数自己的回调。

然后继续回到createSetupStore中，最终

// ...
assign(store, setupStore)
    // allows retrieving reactive objects with `storeToRefs()`. Must be called after assigning to the 		reactive object.
    // Make `storeToRefs()` work with `reactive()` #799
    assign(toRaw(store), setupStore)
// ...
  Object.defineProperty(store, '$state', {
    get: () => (__DEV__ && hot ? hotState.value : pinia.state.value[$id]),
    set: (state) => {
      /* istanbul ignore if */
      if (__DEV__ && hot) {
        throw new Error('cannot set hotState')
      }
      $patch(($state) => {
        assign($state, state)
      })
    },
  })

注意这里的store是前面基于partialStore创建的store，没有数据的，而setupStore则是数据。

接着我们继续往下看：

  // apply all plugins
  pinia._p.forEach((extender) => {
    /* istanbul ignore else */
    if (__USE_DEVTOOLS__ && IS_CLIENT) {
      const extensions = scope.run(() =>
        extender({
          store: store as Store,
          app: pinia._a,
          pinia,
          options: optionsForPlugin,
        })
      )!
      Object.keys(extensions || {}).forEach((key) =>
        store._customProperties.add(key)
      )
      assign(store, extensions)
    } else {
      assign(
        store,
        scope.run(() =>
          extender({
            store: store as Store,
            app: pinia._a,
            pinia,
            options: optionsForPlugin,
          })
        )!
      )
    }
  })

这是在触发插件并把结果赋值给store。

最后一部分：

  if (__DEV__ && !isVue2) {
    $subscribeOptions.onTrigger = (event) => {
      /* istanbul ignore else */
      if (isListening) {
        debuggerEvents = event
        // avoid triggering this while the store is being built and the state is being set in pinia
      } else if (isListening == false && !store._hotUpdating) {
        // let patch send all the events together later
        /* istanbul ignore else */
        if (Array.isArray(debuggerEvents)) {
          debuggerEvents.push(event)
        } else {
          console.error(
            '🍍 debuggerEvents should be an array. This is most likely an internal Pinia bug.'
          )
        }
      }
    }
  }
  isListening = true
  isSyncListening = true
  return store

这里为什么要把isListening和isSyncListening置为true，因为我们的$patch和$subscribe以及watch回调实际上是闭包，如果这里不变成true，那么等这个函数出栈，里面的逻辑就有问题了。

ok，createSetupStore总算是讲完了，我们整理下。

简单整理createSetupStore

基于partialStore（里面包含比如$patch的api）创建reactive store实例，然后将它放入pinia._s（Map<string, StoreGeneric>）中。
调用vue.runWithContext在这个pinia实例对应的vue上下文中执行setup函数获得我们的setupStore也就是store数据
遍历合并setupStore，如果是普通函数则包裹一层用于触发action。
赋值setupStore给store实例
触发插件，把结果合并到store实例
将isListening和isSyncListening置为true，避免函数推出调用栈导致闭包中引用有问题
最后返回store实例。

然后我们再来讲下createOptionsStore

createOptionsStore#

这货就比较简单了，因为格式有板有眼，直接贴代码：

function createOptionsStore<
  Id extends string,
  S extends StateTree,
  G extends _GettersTree<S>,
  A extends _ActionsTree,
>(
  id: Id,
  options: DefineStoreOptions<Id, S, G, A>,
  pinia: Pinia,
  hot?: boolean
): Store<Id, S, G, A> {
  const { state, actions, getters } = options

  const initialState: StateTree | undefined = pinia.state.value[id]

  let store: Store<Id, S, G, A>

  function setup() {
    if (!initialState && (!__DEV__ || !hot)) {
      /* istanbul ignore if */
      if (isVue2) {
        set(pinia.state.value, id, state ? state() : {})
      } else {
        pinia.state.value[id] = state ? state() : {}
      }
    }

    // avoid creating a state in pinia.state.value
    const localState =
      __DEV__ && hot
        ? // use ref() to unwrap refs inside state TODO: check if this is still necessary
          toRefs(ref(state ? state() : {}).value)
        : toRefs(pinia.state.value[id])

    return assign(
      localState,
      actions,
      Object.keys(getters || {}).reduce(
        (computedGetters, name) => {
          if (__DEV__ && name in localState) {
            console.warn(
              `[🍍]: A getter cannot have the same name as another state property. Rename one of them. Found with "${name}" in store "${id}".`
            )
          }

          computedGetters[name] = markRaw(
            computed(() => {
              setActivePinia(pinia)
              // it was created just before
              const store = pinia._s.get(id)!

              // allow cross using stores
              /* istanbul ignore if */
              if (isVue2 && !store._r) return

              // @ts-expect-error
              // return getters![name].call(context, context)
              // TODO: avoid reading the getter while assigning with a global variable
              return getters![name].call(store, store)
            })
          )
          return computedGetters
        },
        {} as Record<string, ComputedRef>
      )
    )
  }

  store = createSetupStore(id, setup, options, pinia, hot, true)

  return store as any
}

这里唯一要说的是computedGetter。

先看下getter的基础用法：

export const useCounterStore = defineStore('counter', {
  state: () => ({
    count: 0,
  }),
  getters: {
    doubleCount: (state) => state.count * 2,
  },
})

回归性原理：getters就是computed！

这里还有一点就是markRaw，说明getter数据改动不会引起响应式更新。

其它没啥好说的了。。。

总结#

我是没想到这一章内容这么多。。。。

简单总结下defineStore里做了什么：

区分你是setupStore还是optionsStore
返回useStore函数，这个函数就是我们业务代码调用时的const xx = useXX()的useXX。
useStore里首先将上下文调整为符合当前pinia实例的vue根实例
根据是否是setupStore分别调用createSetupStore和createOptionsStore
返回上面俩函数执行拿到的store实例
俩函数的逻辑上面总结了，这里就不总结了。

突然发现没了，我们要分析的内容到这里就结束了~

前言#

昨天我们看了cretePinia的逻辑，了解了初始化的逻辑。

今天我们来看下defineStore。

defineStore#

切换测试用例#

昨天我们用的测试用例是没有数据的，今天我们换一个：

这是官方提供的：

const useA = defineStore('a', {
    state: () => ({ a: 'a' }),
})

it('retrieves the root state of one store', () => {
    const pinia = createPinia()
    useA(pinia)
    expect(pinia.state.value).toEqual({
      a: { a: 'a' },
    })
  })

不过我一般的写法是setup stores：

export const useCounterStore = defineStore('counter', () => {
  const count = ref(0)

  function $reset() {
    count.value = 0
  }

  return { count, $reset }
})

所以我这里修改下测试用例

const useC = defineStore('c', () => {
	const user = reactive({
      name: 'c',
      gender: 'male',
      age: 18,
     })
    return {
      user,
    }
  })

it('retrieves the root state of one store', () => {
    const pinia = createPinia()
    useC(pinia)
    expect(pinia.state.value).toEqual({
      c: {
        user: {
          name: 'c',
          gender: 'male',
          age: 18,
        },
      },
    })
  })

源码#

前面一大段的函数重载

export function defineStore<
  Id extends string,
  S extends StateTree = {},
  G extends _GettersTree<S> = {},
  // cannot extends ActionsTree because we loose the typings
  A /* extends ActionsTree */ = {},
>(
  id: Id,
  options: Omit<DefineStoreOptions<Id, S, G, A>, 'id'>
): StoreDefinition<Id, S, G, A>

/**
 * Creates a `useStore` function that retrieves the store instance
 *
 * @param options - options to define the store
 */
export function defineStore<
  Id extends string,
  S extends StateTree = {},
  G extends _GettersTree<S> = {},
  // cannot extends ActionsTree because we loose the typings
  A /* extends ActionsTree */ = {},
>(options: DefineStoreOptions<Id, S, G, A>): StoreDefinition<Id, S, G, A>

/**
 * Creates a `useStore` function that retrieves the store instance
 *
 * @param id - id of the store (must be unique)
 * @param storeSetup - function that defines the store
 * @param options - extra options
 */
export function defineStore<Id extends string, SS>(
  id: Id,
  storeSetup: () => SS,
  options?: DefineSetupStoreOptions<
    Id,
    _ExtractStateFromSetupStore<SS>,
    _ExtractGettersFromSetupStore<SS>,
    _ExtractActionsFromSetupStore<SS>
  >
): StoreDefinition<
  Id,
  _ExtractStateFromSetupStore<SS>,
  _ExtractGettersFromSetupStore<SS>,
  _ExtractActionsFromSetupStore<SS>
>

我们来看下核心代码：

export function defineStore(
  // TODO: add proper types from above
  idOrOptions: any,
  setup?: any,
  setupOptions?: any
): StoreDefinition {
  let id: string
  let options:
    | DefineStoreOptions<
        string,
        StateTree,
        _GettersTree<StateTree>,
        _ActionsTree
      >
    | DefineSetupStoreOptions<
        string,
        StateTree,
        _GettersTree<StateTree>,
        _ActionsTree
      >

  const isSetupStore = typeof setup === 'function'
  if (typeof idOrOptions === 'string') {
    id = idOrOptions
    // the option store setup will contain the actual options in this case
    options = isSetupStore ? setupOptions : setup
  } else {
    options = idOrOptions
    id = idOrOptions.id

    if (__DEV__ && typeof id !== 'string') {
      throw new Error(
        `[🍍]: "defineStore()" must be passed a store id as its first argument.`
      )
    }
  }

  function useStore(pinia?: Pinia | null, hot?: StoreGeneric): StoreGeneric {
    const hasContext = hasInjectionContext()
    pinia =
      // in test mode, ignore the argument provided as we can always retrieve a
      // pinia instance with getActivePinia()
      (__TEST__ && activePinia && activePinia._testing ? null : pinia) ||
      (hasContext ? inject(piniaSymbol, null) : null)
    if (pinia) setActivePinia(pinia)

    if (__DEV__ && !activePinia) {
      throw new Error(
        `[🍍]: "getActivePinia()" was called but there was no active Pinia. Are you trying to use a store before calling "app.use(pinia)"?\n` +
          `See https://pinia.vuejs.org/core-concepts/outside-component-usage.html for help.\n` +
          `This will fail in production.`
      )
    }

    pinia = activePinia!

    if (!pinia._s.has(id)) {
      // creating the store registers it in `pinia._s`
      if (isSetupStore) {
        createSetupStore(id, setup, options, pinia)
      } else {
        createOptionsStore(id, options as any, pinia)
      }

      /* istanbul ignore else */
      if (__DEV__) {
        // @ts-expect-error: not the right inferred type
        useStore._pinia = pinia
      }
    }

    const store: StoreGeneric = pinia._s.get(id)!

    if (__DEV__ && hot) {
      const hotId = '__hot:' + id
      const newStore = isSetupStore
        ? createSetupStore(hotId, setup, options, pinia, true)
        : createOptionsStore(hotId, assign({}, options) as any, pinia, true)

      hot._hotUpdate(newStore)

      // cleanup the state properties and the store from the cache
      delete pinia.state.value[hotId]
      pinia._s.delete(hotId)
    }

    if (__DEV__ && IS_CLIENT) {
      const currentInstance = getCurrentInstance()
      // save stores in instances to access them devtools
      if (
        currentInstance &&
        currentInstance.proxy &&
        // avoid adding stores that are just built for hot module replacement
        !hot
      ) {
        const vm = currentInstance.proxy
        const cache = '_pStores' in vm ? vm._pStores! : (vm._pStores = {})
        cache[id] = store
      }
    }

    // StoreGeneric cannot be casted towards Store
    return store as any
  }

  useStore.$id = id

  return useStore
}

代码量不多，就不做删减了。

idOrOptions：我们defineStore的第一个参数，作为唯一标识符。

setup：我们传入的第二个参数，我们这里传入了一个函数：

() => {
    const user = __vite_ssr_import_3__.reactive({
    	name: "c",
    	gender: "male",
        age: 18
    });
    return {
        user
    };
}

isSetupStore：不多说，我们的写法自然就是setup store，注意，只要传入函数就会被认定是setup store的写法。

最后它返回一个useStore的函数，并把我们的唯一标识符赋值给这个函数$id。

而这个useStore的函数就是我们业务代码中引入的hook，我们需要执行这个hook才能拿到最终的数据：

const userStore = useC()

这里我们不需要传入pinia作为参数，因为我们有全局activePinia。

然后我们来看下useStore执行的逻辑。

hasInjectionContext：这个函数来自于vue（vue-demi）：
typescript · readonly
```
function hasInjectionContext() {
  return !!(currentInstance || currentRenderingInstance || currentApp);
}
```
查看是否可以执行inject逻辑，前面一章我们说过了currentInstance、currentRenderingInstsance的作用以及provide/inject的实现逻辑，所以这里不多说。
pinia = inject(piniaSymbol, null)：没啥好说的，从当前组件实例中拿到pinia，前面一章我们知道了install的时候这货会用vue的provide将自己注入所有组件实例中，所以理论上是拿得到的。
if (pinia) setActivePinia(pinia)：这里是将全局的activePinia设置成当前组件实例绑定的pinia实例。你可呢在疑惑为什么要这么做，install到vue根组件的时候不是已经这么做了吗？为什么还要再设置一次？因为不一定只有一个vue根组件，也不一定只有一个pinia实例。可能存在两个pinia实例，比如：
typescript · readonly
```
  it('does not mix up different applications', () => {
    const pinia1 = createPinia()
    const pinia2 = createPinia()
    useA(pinia1)
    useB(pinia2)
    expect(pinia1.state.value).toEqual({
      a: { a: 'a' },
    })
    expect(pinia2.state.value).toEqual({
      b: { b: 'b' },
    })
  })

const app1 = createApp(App1).mount('a').use(pinia1);
const app2 = createApp(App2).mount('b').use(pinia2);
```
这就是俩pinia实例，另外这个项目中可能存在多个vue根组件实例，每个实例单独use一个pinia实例。但是我们只有一个activePinia位置！这玩意儿全局只有一个！。那么这个时候activePinia指向就不一定准了。
pinia._s：_s: Map<string, StoreGeneric>，存放的是defineStore里的数据，key自然就是defineStore第一个参数。
createSetupStore：这玩意儿代码有些长。。我们等会开个小章节说下，这里先跳过
createOptionsStore：这个和createSetupStore放到一起说，所以这里也先跳过
const store: StoreGeneric = pinia._s.get(id)!：这货就是我们useXX返回的数据，指向我们定义的store数据

剩余部分的代码是和开发阶段热更新有关的，官方链接：HMR (Hot Module Replacement) | Pinia (vuejs.org)

这里简单说下：如果是vite，那么开箱即用，vite支持自定义热更新内容（当然，webpack等也支持，不过写法不一样）：HMR API | Vite (vitejs.dev)

// auth.js
import { defineStore, acceptHMRUpdate } from 'pinia'

export const useAuth = defineStore('auth', {
  // options...
})

// make sure to pass the right store definition, `useAuth` in this case.
if (import.meta.hot) {
  import.meta.hot.accept(acceptHMRUpdate(useAuth, import.meta.hot))
}

这么做就可以搭vite热更新的车了。

具体如何实现的，因为涉及到vite热更新的原理，我们以后再分析，现阶段先跳过。

createSetupStore#

这货代码较长，我这里就不贴整体的了，我们拆开了一部分一部分分析：

函数整体：

function createSetupStore<
  Id extends string,
  SS extends Record<any, unknown>,
  S extends StateTree,
  G extends Record<string, _Method>,
  A extends _ActionsTree,
>(
  $id: Id,
  setup: () => SS,
  options:
    | DefineSetupStoreOptions<Id, S, G, A>
    | DefineStoreOptions<Id, S, G, A> = {},
  pinia: Pinia,
  hot?: boolean,
  isOptionsStore?: boolean
): Store<Id, S, G, A> {
    // ...
      const store: Store<Id, S, G, A> = reactive(
    	__DEV__ || (__USE_DEVTOOLS__ && IS_CLIENT)
      ? assign(
          {
            _hmrPayload,
            _customProperties: markRaw(new Set<string>()), // devtools custom properties
          },
          partialStore
          // must be added later
          // setupStore
        )
      : partialStore
  	) as unknown as Store<Id, S, G, A>

    pinia._s.set($id, store as Store)
    // ...
    return store
}

可以看到最终是返回一个reactive包裹的响应式store数据，这个数据就是最终我们useXX返回的数据,对应前面useStore函数的返回store。

然后我们来看下这个partialStore：

  const partialStore = {
    _p: pinia,
    // _s: scope,
    $id,
    $onAction: addSubscription.bind(null, actionSubscriptions),
    $patch,
    $reset,
    $subscribe(callback, options = {}) {
      const removeSubscription = addSubscription(
        subscriptions,
        callback,
        options.detached,
        () => stopWatcher()
      )
      const stopWatcher = scope.run(() =>
        watch(
          () => pinia.state.value[$id] as UnwrapRef<S>,
          (state) => {
            if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(
                {
                  storeId: $id,
                  type: MutationType.direct,
                  events: debuggerEvents as DebuggerEvent,
                },
                state
              )
            }
          },
          assign({}, $subscribeOptions, options)
        )
      )!

      return removeSubscription
    },
    $dispose,
  } as _StoreWithState<Id, S, G, A>

_p：这里注意和pinia实例的_p区分开来，pinia实例的_p指向pinia的插件。这里则指向pinia实例。

然后没啥好说的了，这就是在初始化一个store实例。

我们接着看下每个property是干啥用的。

$onAction

首先是犯下傲慢的$onAction：Interface: _StoreWithState | Pinia (vuejs.org)

$onAction: addSubscription.bind(null, actionSubscriptions)

export function addSubscription<T extends _Method>(
  subscriptions: T[],
  callback: T,
  detached?: boolean,
  onCleanup: () => void = noop
) {
  subscriptions.push(callback)

  const removeSubscription = () => {
    const idx = subscriptions.indexOf(callback)
    if (idx > -1) {
      subscriptions.splice(idx, 1)
      onCleanup()
    }
  }

  if (!detached && getCurrentScope()) {
    onScopeDispose(removeSubscription)
  }

  return removeSubscription
}

就是一个简单的订阅和取消订阅的方法，这里只是订阅，还没涉及到发布。

所以这个$onAction就是用来订阅的，另外根据官方文档的描述：

Setups a callback to be called every time an action is about to get invoked

这货可以用在每次action触发后的回调。

返回一个函数用来手动注销回调。

看下基础用法：

store.$onAction(({ after, onError }) => {
 // Here you could share variables between all of the hooks as well as
 // setting up watchers and clean them up
 after((resolvedValue) => {
   // can be used to cleanup side effects
.  // `resolvedValue` is the value returned by the action, if it's a
.  // Promise, it will be the resolved value instead of the Promise
 })
 onError((error) => {
   // can be used to pass up errors
 })
})

然后我们再来看下$patch

$patch

Interface: _StoreWithState | Pinia (vuejs.org)

在看代码之前，我们先看下基础用法：

          store.$patch({ user })
		 // or
          store.$patch((state) => {
            state.user = name
          })

然后看下代码

  // avoid triggering too many listeners
  // https://github.com/vuejs/pinia/issues/1129
  let activeListener: Symbol | undefined
  function $patch(stateMutation: (state: UnwrapRef<S>) => void): void
  function $patch(partialState: _DeepPartial<UnwrapRef<S>>): void
  function $patch(
    partialStateOrMutator:
      | _DeepPartial<UnwrapRef<S>>
      | ((state: UnwrapRef<S>) => void)
  ): void {
    let subscriptionMutation: SubscriptionCallbackMutation<S>
    isListening = isSyncListening = false
    // reset the debugger events since patches are sync
    /* istanbul ignore else */
    if (__DEV__) {
      debuggerEvents = []
    }
    if (typeof partialStateOrMutator === 'function') {
      partialStateOrMutator(pinia.state.value[$id] as UnwrapRef<S>)
      subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    } else {
      mergeReactiveObjects(pinia.state.value[$id], partialStateOrMutator)
      subscriptionMutation = {
        type: MutationType.patchObject,
        payload: partialStateOrMutator,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    }
    const myListenerId = (activeListener = Symbol())
    nextTick().then(() => {
      if (activeListener === myListenerId) {
        isListening = true
      }
    })
    isSyncListening = true
    // because we paused the watcher, we need to manually call the subscriptions
    triggerSubscriptions(
      subscriptions,
      subscriptionMutation,
      pinia.state.value[$id] as UnwrapRef<S>
    )
  }

代码稍微复杂了点。

export type UnwrapRef<T> = T extends ShallowRef<infer V> ? V : T extends Ref<infer V> ? UnwrapRefSimple<V> : UnwrapRefSimple<T>;

export type ShallowRef<T = any> = Ref<T> & {
    [ShallowRefMarker]?: true;
};

export interface Ref<T = any> {
    value: T;
    /**
     * Type differentiator only.
     * We need this to be in public d.ts but don't want it to show up in IDE
     * autocomplete, so we use a private Symbol instead.
     */
    [RefSymbol]: true;
}

type UnwrapRefSimple<T> = T extends Builtin | Ref | RefUnwrapBailTypes[keyof RefUnwrapBailTypes] | {
    [RawSymbol]?: true;
} ? T : T extends Map<infer K, infer V> ? Map<K, UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof Map<any, any>>> : T extends WeakMap<infer K, infer V> ? WeakMap<K, UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof WeakMap<any, any>>> : T extends Set<infer V> ? Set<UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof Set<any>>> : T extends WeakSet<infer V> ? WeakSet<UnwrapRefSimple<V>> & UnwrapRef<Omit<T, keyof WeakSet<any>>> : T extends ReadonlyArray<any> ? {
    [K in keyof T]: UnwrapRefSimple<T[K]>;
} : T extends object & {
    [ShallowReactiveMarker]?: never;
} ? {
    [P in keyof T]: P extends symbol ? T[P] : UnwrapRef<T[P]>;
} : T;


S extends StateTree,

不是我不想解释，实在是太类型体操了。

简单的说下UnwrapRef<T>的作用，就是用来取消ref包裹数据的那一层。

原本我们需要调用.value才能访问到这个数据，使用UnwrapRef<T>之后就不需要了。

来看下官方的例子：Reactivity Fundamentals | Vue.js (vuejs.org)

const count = ref(0)
const state = reactive({
  count
})

console.log(state.count) // 0

state.count = 1
console.log(count.value) // 1

当它被赋值给一个reactive的属性的时候它会自动解除外面那一层。

前面我们知道了usexx返回的就是一个reactive的store实例，所以这里state自然就是UnwrapRef。

不过这里你可能会有疑惑，为什么传给我们回调的是pinia.state.value[$id]

这就需要我们回到createPinia那里：

  const scope = effectScope(true)
  // NOTE: here we could check the window object for a state and directly set it
  // if there is anything like it with Vue 3 SSR
  const state = scope.run<Ref<Record<string, StateTree>>>(() =>
    ref<Record<string, StateTree>>({})
  )!

这里的state就是上面的pinia.state，因为pinia本身是raw的，所以state并不能变成UnwrapRef。

ok，但是这里还有个问题，初始化的时候是空的，这里却是从里面拿出store来，这不对啊。

实际上前面还有逻辑我没给出：

  const initialState = pinia.state.value[$id] as UnwrapRef<S> | undefined

  // avoid setting the state for option stores if it is set
  // by the setup
  if (!isOptionsStore && !initialState && (!__DEV__ || !hot)) {
    /* istanbul ignore if */
    if (isVue2) {
      set(pinia.state.value, $id, {})
    } else {
      pinia.state.value[$id] = {}
    }
  }

	// ...
    if (typeof partialStateOrMutator === 'function') {
      partialStateOrMutator(pinia.state.value[$id] as UnwrapRef<S>)
      subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
      }
    }
	// ...

那么到这我们就知道了为什么这里是从pinia.state.value[$id]中拿到的数据。

貌似扯的有些远了，我们回到之前的代码，在执行完我们传入的函数之后。

我们前面看的$onAction就是设置回调可以在每次action之后执行回调，那么这里我们在更新数据之后就需要触发回调（pinia只有action）。

则例isListening和isSyncListening俩参数暂时还不清楚是干什么用的，所以先暂时搁置，后面遇到再解释。

triggerSubscriptions：

export function triggerSubscriptions<T extends _Method>(
  subscriptions: T[],
  ...args: Parameters<T>
) {
  subscriptions.slice().forEach((callback) => {
    callback(...args)
  })
}

就是简单的执行回调，注意是slice是clone一个，而不是直接占用。

这里args里有俩参数：

if (__DEV__) {
   debuggerEvents = []
}
// args第一个参数
subscriptionMutation = {
        type: MutationType.patchFunction,
        storeId: $id,
        events: debuggerEvents as DebuggerEvent[],
 }
// args第二个参数
pinia.state.value[$id] as UnwrapRef<S>

注意这里第一个参数里有一个debuggerEvents，只有开发阶段才能使用，我们可以往里面传入debug回调。

到这我们暂时只知道如何存储，还不知道如何调用，等会遇到了我们再说。

ok, $patch分析到这，我们有俩个点还没分析：

debuggerEvents
isListening以及isSyncListening

然后我们来看下$reset

$reset

Interface: _StoreWithState | Pinia (vuejs.org)

Resets the store to its initial state by building a new state object.

不多说，直接看代码

  const $reset = isOptionsStore
    ? function $reset(this: _StoreWithState<Id, S, G, A>) {
        const { state } = options as DefineStoreOptions<Id, S, G, A>
        const newState = state ? state() : {}
        // we use a patch to group all changes into one single subscription
        this.$patch(($state) => {
          assign($state, newState)
        })
      }
    : /* istanbul ignore next */
      __DEV__
      ? () => {
          throw new Error(
            `🍍: Store "${$id}" is built using the setup syntax and does not implement $reset().`
          )
        }
      : noop

可以看到只有使用optionStore的时候才可行，为什么呢？

因为我们用的是setup语法，没有state函数。

总之，setupStore需要开发者手动实现初始化函数，因为不像optionStore一样是一个对象很好管理。

然后我们来看下$subscribe

$subscribe

Interface: _StoreWithState | Pinia (vuejs.org)

Setups a callback to be called whenever the state changes. It also returns a function to remove the callback. Note that when calling store.$subscribe() inside of a component, it will be automatically cleaned up when the component gets unmounted unless detached is set to true.

{
// ...
$subscribe(callback, options = {}) {
      const removeSubscription = addSubscription(
        subscriptions,
        callback,
        options.detached,
        () => stopWatcher()
      )
      const stopWatcher = scope.run(() =>
        watch(
          () => pinia.state.value[$id] as UnwrapRef<S>,
          (state) => {
            if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(
                {
                  storeId: $id,
                  type: MutationType.direct,
                  events: debuggerEvents as DebuggerEvent,
                },
                state
              )
            }
          },
          assign({}, $subscribeOptions, options)
        )
      )!

      return removeSubscription
    }
// ...
}

先将我们的回调放入到订阅器中，不过和前面$onAction不同的是这里还传入了一个() => stopWatcher()作为addSubscription的第四个参数onCleanup，在执行函数返回的函数即注销回调会执行这个onCleanup。触发stopWatcher
stopWatcher中有个scope，我们来看下这货是从哪来的：

// pinia里的
function createSetupStore (...) {
    let scope!: EffectScope
    // ...
 const partialStore = { ... };
 const store = reactive(...);

 const runWithContext = (pinia._a && pinia._a.runWithContext) || fallbackRunWithContext

  // TODO: idea create skipSerialize that marks properties as non serializable and they are skipped
  const setupStore = runWithContext(() =>
    pinia._e.run(() => (scope = effectScope()).run(setup)!)
  )!
}


// vue里的
    /**
     * Runs a function with the app as active instance. This allows using of `inject()` within the function to get access
     * to variables provided via `app.provide()`.
     *
     * @param fn - function to run with the app as active instance
     */
    runWithContext<T>(fn: () => T): T;

const app = {
    // ...
      runWithContext(fn) {
        const lastApp = currentApp;
        currentApp = app;
        try {
          return fn();
        } finally {
          currentApp = lastApp;
        }
      }
    // ...
}

_a：这货前面说过了，就是这个pinia实例注册的那个vue根实例
runWithContext：这个则是vue里的函数，用来确保当前执行函数的上下文是对应的vue根实例。
_e： EffectScope，这货是pinia实例初始化即createPinia时触发的effectscope。

简单的说就是创建一个当前store的effectScope，用来收集store（我们传入的setup函数）里的响应式数据

这里我们遇到了前面没说的isSyncListening和isListening字段

然后我们结合$patch里的逻辑，整理下：

let isListening: boolean // set to true at the end
let isSyncListening: boolean // set to true at the end
let activeListener: Symbol | undefined
const partialStore = {
    // ...
	$patch () {

   		isListening = isSyncListening = false
    	// ...
		const myListenerId = (activeListener = Symbol())
    	nextTick().then(() => {
      		if (activeListener === myListenerId) {
        		isListening = true
      		}
    	})
    	isSyncListening = true
    // ...
	}
    // ...
    $subscribe () {
        // ...
        const stopWatcher = scope.run(() => watch(
        	// ...
             if (options.flush === 'sync' ? isSyncListening : isListening) {
              callback(...)
			}
        ))
        // ...
    }
}

export interface WatchOptionsBase extends DebuggerOptions {
    flush?: 'pre' | 'post' | 'sync';
}

这里需要补充watch的知识：Watchers | Vue.js (vuejs.org)

默认情况下，watch回调是在父组件更新后子组件DOM更新前触发（flush: sync），这么做是避免watch里改动数据引起重复渲染。

当然，如果你有这方面的想法，想在子组件（当前组件）更新之后再执行，可以设置flush: post：

watch(source, callback, {
  flush: 'post'
})

watchEffect(callback, {
  flush: 'post'
})

import { watchPostEffect } from 'vue'

watchPostEffect(() => {
  /* executed after Vue updates */
})

或者说在这之前获取：

watch(source, callback, {
  flush: 'sync'
})

watchEffect(callback, {
  flush: 'sync'
})

import { watchSyncEffect } from 'vue'

watchSyncEffect(() => {
  /* executed synchronously upon reactive data change */
})

而$subscribe里的watch只能在flush和post两种情况下执行，记录isListening是确保不会执行错回调，毕竟这个回调只能在这个store实例数据刷新后执行。

ok，还剩最后一个$dispose

$dispose

Interface: _StoreWithState | Pinia (vuejs.org)

  function $dispose() {
    scope.stop()
    subscriptions = []
    actionSubscriptions = []
    pinia._s.delete($id)
  }

这货不用多说，就是remove这个store实例。

ok，跳出partialStrore回到我们的createSetupStore函数中

在执行了runWithContext之后我们拿到了setupStore，为了方便分析，我加了点其它的东西

然后我们接着看代码（部分dev和hmr相关的代码省略）：

// ...
for (const key in setupStore) {
    const prop = setupStore[key]

    if ((isRef(prop) && !isComputed(prop)) || isReactive(prop)) {
        if (!isOptionsStore) {
        	// in setup stores we must hydrate the state and sync pinia state tree with the refs the 			user just created
        	if (initialState && shouldHydrate(prop)) {
          	if (isRef(prop)) {
            	prop.value = initialState[key]
          	} else {
            	// probably a reactive object, lets recursively assign
            	// @ts-expect-error: prop is unknown
            	mergeReactiveObjects(prop, initialState[key])
          	}
        }
        // transfer the ref to the pinia state to keep everything in sync
        /* istanbul ignore if */
        if (isVue2) {
          set(pinia.state.value[$id], key, prop)
        } else {
          pinia.state.value[$id][key] = prop
        }
      }
    } else if (typeof prop === 'function') {
             // @ts-expect-error: we are overriding the function we avoid wrapping if
      		const actionValue = __DEV__ && hot ? prop : wrapAction(key, prop)
      		// this a hot module replacement store because the hotUpdate method needs
      		// to do it with the right context
      		/* istanbul ignore if */
      		if (isVue2) {
        		set(setupStore, key, actionValue)
      		} else {
        		// @ts-expect-error
        		setupStore[key] = actionValue
      		}
             // list actions so they can be used in plugins
      		// @ts-expect-error
      		optionsForPlugin.actions[key] = prop
    }
 // ...
 }
// ...

/**
 * Returns whether a value should be hydrated
 *
 * @param obj - target variable
 * @returns true if `obj` should be hydrated
*/
export function isPlainObject(
  // eslint-disable-next-line @typescript-eslint/no-explicit-any
  o: any
): o is StateTree {
  return (
    o &&
    typeof o === 'object' &&
    Object.prototype.toString.call(o) === '[object Object]' &&
    typeof o.toJSON !== 'function'
  )
}
const skipHydrateSymbol = Symbol();
function shouldHydrate(obj: any) {
  return isVue2
    ? /* istanbul ignore next */ !skipHydrateMap.has(obj)
    : !isPlainObject(obj) || !obj.hasOwnProperty(skipHydrateSymbol)
}

shouldHydrate：是否需要注入，如果是对象并且不在store中，那就需要合并
mergeReactiveObjects：篇幅问题，这里就不贴代码了，就是在合并响应式数据

wrapAction：这货得看下代码：

  /**
   * Wraps an action to handle subscriptions.
   *
   * @param name - name of the action
   * @param action - action to wrap
   * @returns a wrapped action to handle subscriptions
   */
  function wrapAction(name: string, action: _Method) {
    return function (this: any) {
      setActivePinia(pinia)
      const args = Array.from(arguments)

      const afterCallbackList: Array<(resolvedReturn: any) => any> = []
      const onErrorCallbackList: Array<(error: unknown) => unknown> = []
      function after(callback: _ArrayType<typeof afterCallbackList>) {
        afterCallbackList.push(callback)
      }
      function onError(callback: _ArrayType<typeof onErrorCallbackList>) {
        onErrorCallbackList.push(callback)
      }

      // @ts-expect-error
      triggerSubscriptions(actionSubscriptions, {
        args,
        name,
        store,
        after,
        onError,
      })

      let ret: unknown
      try {
        ret = action.apply(this && this.$id === $id ? this : store, args)
        // handle sync errors
      } catch (error) {
        triggerSubscriptions(onErrorCallbackList, error)
        throw error
      }

      if (ret instanceof Promise) {
        return ret
          .then((value) => {
            triggerSubscriptions(afterCallbackList, value)
            return value
          })
          .catch((error) => {
            triggerSubscriptions(onErrorCallbackList, error)
            return Promise.reject(error)
          })
      }

      // trigger after callbacks
      triggerSubscriptions(afterCallbackList, ret)
      return ret
    }
  }

它是用于普通函数的。简单的说就是包裹一层普通函数，让它也能触发action回调以及函数自己的回调。

然后继续回到createSetupStore中，最终

// ...
assign(store, setupStore)
    // allows retrieving reactive objects with `storeToRefs()`. Must be called after assigning to the 		reactive object.
    // Make `storeToRefs()` work with `reactive()` #799
    assign(toRaw(store), setupStore)
// ...
  Object.defineProperty(store, '$state', {
    get: () => (__DEV__ && hot ? hotState.value : pinia.state.value[$id]),
    set: (state) => {
      /* istanbul ignore if */
      if (__DEV__ && hot) {
        throw new Error('cannot set hotState')
      }
      $patch(($state) => {
        assign($state, state)
      })
    },
  })

注意这里的store是前面基于partialStore创建的store，没有数据的，而setupStore则是数据。

接着我们继续往下看：

  // apply all plugins
  pinia._p.forEach((extender) => {
    /* istanbul ignore else */
    if (__USE_DEVTOOLS__ && IS_CLIENT) {
      const extensions = scope.run(() =>
        extender({
          store: store as Store,
          app: pinia._a,
          pinia,
          options: optionsForPlugin,
        })
      )!
      Object.keys(extensions || {}).forEach((key) =>
        store._customProperties.add(key)
      )
      assign(store, extensions)
    } else {
      assign(
        store,
        scope.run(() =>
          extender({
            store: store as Store,
            app: pinia._a,
            pinia,
            options: optionsForPlugin,
          })
        )!
      )
    }
  })

这是在触发插件并把结果赋值给store。

最后一部分：

  if (__DEV__ && !isVue2) {
    $subscribeOptions.onTrigger = (event) => {
      /* istanbul ignore else */
      if (isListening) {
        debuggerEvents = event
        // avoid triggering this while the store is being built and the state is being set in pinia
      } else if (isListening == false && !store._hotUpdating) {
        // let patch send all the events together later
        /* istanbul ignore else */
        if (Array.isArray(debuggerEvents)) {
          debuggerEvents.push(event)
        } else {
          console.error(
            '🍍 debuggerEvents should be an array. This is most likely an internal Pinia bug.'
          )
        }
      }
    }
  }
  isListening = true
  isSyncListening = true
  return store

ok，createSetupStore总算是讲完了，我们整理下。

简单整理createSetupStore

基于partialStore（里面包含比如$patch的api）创建reactive store实例，然后将它放入pinia._s（Map<string, StoreGeneric>）中。
调用vue.runWithContext在这个pinia实例对应的vue上下文中执行setup函数获得我们的setupStore也就是store数据
遍历合并setupStore，如果是普通函数则包裹一层用于触发action。
赋值setupStore给store实例
触发插件，把结果合并到store实例
将isListening和isSyncListening置为true，避免函数推出调用栈导致闭包中引用有问题
最后返回store实例。

然后我们再来讲下createOptionsStore

createOptionsStore#

这货就比较简单了，因为格式有板有眼，直接贴代码：

function createOptionsStore<
  Id extends string,
  S extends StateTree,
  G extends _GettersTree<S>,
  A extends _ActionsTree,
>(
  id: Id,
  options: DefineStoreOptions<Id, S, G, A>,
  pinia: Pinia,
  hot?: boolean
): Store<Id, S, G, A> {
  const { state, actions, getters } = options

  const initialState: StateTree | undefined = pinia.state.value[id]

  let store: Store<Id, S, G, A>

  function setup() {
    if (!initialState && (!__DEV__ || !hot)) {
      /* istanbul ignore if */
      if (isVue2) {
        set(pinia.state.value, id, state ? state() : {})
      } else {
        pinia.state.value[id] = state ? state() : {}
      }
    }

    // avoid creating a state in pinia.state.value
    const localState =
      __DEV__ && hot
        ? // use ref() to unwrap refs inside state TODO: check if this is still necessary
          toRefs(ref(state ? state() : {}).value)
        : toRefs(pinia.state.value[id])

    return assign(
      localState,
      actions,
      Object.keys(getters || {}).reduce(
        (computedGetters, name) => {
          if (__DEV__ && name in localState) {
            console.warn(
              `[🍍]: A getter cannot have the same name as another state property. Rename one of them. Found with "${name}" in store "${id}".`
            )
          }

          computedGetters[name] = markRaw(
            computed(() => {
              setActivePinia(pinia)
              // it was created just before
              const store = pinia._s.get(id)!

              // allow cross using stores
              /* istanbul ignore if */
              if (isVue2 && !store._r) return

              // @ts-expect-error
              // return getters![name].call(context, context)
              // TODO: avoid reading the getter while assigning with a global variable
              return getters![name].call(store, store)
            })
          )
          return computedGetters
        },
        {} as Record<string, ComputedRef>
      )
    )
  }

  store = createSetupStore(id, setup, options, pinia, hot, true)

  return store as any
}

这里唯一要说的是computedGetter。

先看下getter的基础用法：

export const useCounterStore = defineStore('counter', {
  state: () => ({
    count: 0,
  }),
  getters: {
    doubleCount: (state) => state.count * 2,
  },
})

回归性原理：getters就是computed！

这里还有一点就是markRaw，说明getter数据改动不会引起响应式更新。

其它没啥好说的了。。。

总结#

我是没想到这一章内容这么多。。。。

简单总结下defineStore里做了什么：

区分你是setupStore还是optionsStore
返回useStore函数，这个函数就是我们业务代码调用时的const xx = useXX()的useXX。
useStore里首先将上下文调整为符合当前pinia实例的vue根实例
根据是否是setupStore分别调用createSetupStore和createOptionsStore
返回上面俩函数执行拿到的store实例
俩函数的逻辑上面总结了，这里就不总结了。

突然发现没了，我们要分析的内容到这里就结束了~
